SKU: 4X4FORCE-BLW-U2101-G029

Ultimate Guard Bullbar No Loop Skid Plate Light Winch for Toyota Hilux Vigo SYD

$2,000.00
RRP $2,400.00
SAVE $400.00 (17%)
In Stock


Calculate Shipping



Local Pickup - $0.00
Pickup from Sydney Warehouse
Australia Post-Eparcel - $0.00
Australia Post Parcel Post
Australia Express Post - $0.00

Description

4X4FORCE bull bars help protect your vehicle from animal strikes when driving on remote roads, and provide convenient locations to mount other 4x4 accessories such as winches, lights and aerials.

4X4FORCE bull bar is carefully crafted from premium grade materials and components to deliver the most comprehensive frontal protection and styling available.

Each 4X4FORCE bull bar is specifically designed to complement the unique contours of individual vehicle models. This ensures the best possible fit, look and functionality for a particular vehicle. All 4X4FORCE bars are finished in a durable powder coat.

Features:

ADR Approved
Winch compatibleParker / Indicator included
A-Frame triple loop design
Tough polyurethane bumpers
Steel construction

4X4FORCE LED Light is Your Wise Choice.

Using a special design of the LED constant current source power supply circuit, the performance is very stable, long life, 50,000 hours, the protection of the environment, you can enjoy using it.Each light has using OSRAM P8 chip, and it is durable, low power consumption. Safe to use.

Features:

* Lifespan: up to 50,000 h
* Easy to install
* IP68 dust & Waterproof
* Heavy duty powdercoated steel mount
* Extended illumination distance
* Blistering bright performance
* Combo Beam

WINCH'S CLASSIFICATION AND FEATURES

13500LB WINCH SPECIFICATIONS

Rated Line Pull 13500LBS (6123kgs) single line
Control Wireless Remote
Gear train 3 Stage Planetary
Packing Size 590 x 315 x 230mm
1.8m Negative Pole Cable
Control Box with 3 x 0.45cm Cables + 1 x 1.8m Long Cable
Power Switch + 2m 3-Pin Plug Extension Cord + 32cm Cable + Switch Mounting Bracket



PULL. SPEED. AMPERES. VOLTS

Line pull lbs(kgs] Line speed ft/min(m/min) Current A
0 24.9(7.6) 70
1500(680) 17.1(5.2) 160
3500(1588) 11.5(3.5) 220
5500(2495) 9.2(2.8) 260
7500(3402) 7.9(2.4) 310
13500(6123) 6.2(1.9) 380



LINE PULL AND ROPE CAPACITY IN LAYER

Layer Rated Line Pull lbs(kgs) Total Rope on Drum ft(m)
1 13500(6123) 13(5)
2 10200(4636) 23(11)
3 8705(3956) 69(21)
4 7310(3323) 92(28)

Features

Note: eBay's compatibility table is not accurate in some cases. Please refer to the following information we have provided for you.

Copyright © 2014 - 2023 United Autoparts. All rights reserved.

Contents:

1 Set 4X4FORCE Front Performance Guard Bumper Winch Bullbar W/Skid Plate

Pair 4X4FORCE 9 Inch Solid Round LED Driving Light 7900 Lumen

4X4FORCE Electricity 4WD Recovery Winch Kit

Bull Bar Specifics:

Style: W/O LOOP
Material: Heavy Duty Steel ; Powder Coated

Lights Parameter :

Size : 9 inch
Leds: 32
Wattage: 160W
Effect Lumens: 15800LM



Suits:Toyota Hilux Vigo 2012-2015

Specifications

SKU 4X4FORCE-BLW-U2101-G029
Brand 4X4FORCE
